STREET LIGHTING

S LUM GEN 3

LUM Gen 3 is the third generation of our LED luminaire, designed for efficient lighting of roads, streets, parking lots, and residential areas. A durable cast aluminum housing and a special design for efficient cooling ensure a long lifetime (L80/B10 @ h). Available in four sizes and with different optics, it can be adapted to different heights and project requirements.

System efficiency up to 165 lm/W
Tool-free access
Separate lighting and power supply sections
Zhaga socket on top
Screwless replacement of the ballast
High-pressure die-cast aluminum
Compatible with IoT
More Send inquiry

Technical specifications

Luminaires S LUM GEN 3
System efficiency [lm/W] to 165
Color rendering index (CRI, Ra) >70
Power (W) 10 - 200
Luminous flux (lm) 1400 - 32000
Correlated color temperature (CCT, K) 2700, 3000, 4000
Intrusion protection IP66
Surge protection (SPD) 10kV / 10kA
Operating temperature [°C] from -40 to +55
Lifetime [h] L90B10 > 100000
Standard warranty (years) 5
Optics
Areas of application Road types: P1-P7, M1-M6, C0-C5, Small sports fields, Parking lots
LED.svg
LED.svg
Zhaga socket.
Zhaga socket.
Connection voltage.
Connection voltage.
Electrical shock protection class I
Electrical shock protection class I
Electrical shock protection class II
Electrical shock protection class II
Degree of protection of the housing against the ingress of solid particles and water according to IEC 60529.
Degree of protection of the housing against the ingress of solid particles and water according to IEC 60529.
Mechanical resistance rating of the housing according to IEC 62262.
Mechanical resistance rating of the housing according to IEC 62262.
Možnost upravljanja.
Možnost upravljanja.
Možnost upravljanja.
Možnost upravljanja.
High system efficiency.
High system efficiency.
Easy installation
Easy installation
Overload protection.
Overload protection.
Overvoltage protection.
Overvoltage protection.
Dimming option.
Dimming option.
Programmable LED driver.
Programmable LED driver.
Recycled materials.
Recycled materials.
Long lifetime (L80/B10 @ h)
Long lifetime (L80/B10 @ h)
The product complies with the basic safety, health, and environmental requirements of EU legislation.
The product complies with the basic safety, health, and environmental requirements of EU legislation.
Certified according to European safety standards (EN) by an independent body.
Certified according to European safety standards (EN) by an independent body.
Optics
Slider ikona nazaj
Slider ikona naprej
Documentation S LUM GEN 3
LDT files LDT
BIM files BIM
Certificates Ikona
Installation instructions Installation
General catalogue luminaries 2025 General
Slika dokumentacija
S LUM GEN 3
Luminaires S LUM GEN 3
